The
American Water Works Association (
AWWA), the leading non-profit, scientific and educational association dedicated to water management and treatment. AWWA members include water utilities, treatment plant operators and managers, and manufacturers. The AWWA maintains and regulates the design and performance standards of valves and actuators used in municipal water treatment and distribution systems. The following are the standards with links for additional information:
This standard describes iron-body, brass-mounted, non-rising stem (NRS) gate valves, including tapping gate valves, 3-in. (75-mm) NPS through 48-in. (1,200-mm) NPS, and outside screw and yoke (OS&Y) rising-stem gate valves, 3-in. (75-mm) NPS through 24-in. (600-mm) NPS, with either double-disc gates having parallel or inclined seats, or solid-wedge gates. These valves are suitable for use in approximately level settings in water systems. These valves are intended for applications where fluid velocities do not exceed 16 ft/sec (4.9 m/sec) when the valve is in the fully open position. The major revisions in this edition of ANSI/AWWA C500 include the following: editorial changes to conform to current AWWA form and content; permitting the use of stainless-steel stems and reduced-thickness ductile-iron flanges; addition of stainless steel as a stem material; addition of a "non-integral thrust collar" for stems in NRS valves; addition of aluminum-bronze and silicon-bronze copper alloys; provision for reduced flange thickness for end flanges of ductile-iron flanged valves; addition of 14-in. and 18-in. valve sizes; and, addition of metric fasteners and socket head fasteners.
This standard describes the double check valve back flow prevention assembly. The assembly shall be for operation on hot or cold water lines and capable of withstanding a working water pressure of at least 150 psi (1,034 kPa) without damage to working parts or impairment of function. This standard describes hot- and cold-water double check valve back flow prevention assemblies. Assemblies shall be designed to operate at a minimum temperature range of 33ºF to 140ºF (1ºC to 60ºC). Hot water assemblies shall be designed to operate, at a minimum, in water at a temperature range of 33ºF to 180ºF (1ºC to 82ºC). A complete assembly consists of two internally loaded, independently operating check valves, located between two tightly closing resilient-seated shutoff valves, with four properly placed resilient-seated test cocks (see Sec. 4.3.1.3). Major revisions made to the standard in this revision include the following: AWWA standard materials statement has been added (Sec. III.A.2 and Sec. 4.1); synthetic coating of ferrous bodies has been removed (Sec. 4.1.2); the material callouts have been updated (Sec. 4.1.3); the identification of nominal size of the assembly has been revised (4.2.1.1); the requirements for structural capability and operational capability have been revised (Sec. 4.2.2.1 and Sec. 4.2.2.2); the sections on area of waterways, clearance of moving parts, facing rings for poppet-type valves, facing rings for swing-type valves, and bushings have been removed (former Sec. 4.3.1.2 through Sec. 4.3.1.6); the requirements for shutoff valves have been updated (Sec. 4.3.1.6); requirements for operational cycle testing have been added (Sec. 4.3.2.3); and, requirements for replacement parts have been added (Sec. 4.3.4).
This standard covers gray-iron, ductile-iron, and cast-steel, flanged-end, low-leakage, shaft- or trunnion-mounted, full-port, double- and single-seated
ball valves for pressures up to 150 psi (1,050 kPa) in sizes 6-in. through 60-in. (150-mm through 1,500-mm) diameter and pressures up to 300 psi (2,100 kPa) in sizes from 6-in. through 48-in. (150-mm through 1,200-mm) diameter for use in water, wastewater, and reclaimed water systems having water with a pH greater than 6 and less than 12 and with temperatures greater than 32ºF (0ºC) and less than 125ºF (52ºC). Design fluid velocity - the valve assembly shall be structurally suitable for a port fluid velocity of 35 ft/sec (10.7 m/sec) at design pressure and shall be within the allowable stresses noted in Sec. 4.3.1. Pressure class and rated/design pressure - the classes of valves discussed in this standard shall be designed for the maximum rated pressure. Rated pressure is defined as the design pressure at 100ºF (38ºC). The major changes made in this revision of the standard include the following: added sizes 54 in. and 60 in. (1,350 mm and 1,500 mm); added paragraph 25 in Section III regarding the consideration of requiring pulls less than 80 lb (356 N) for hand-wheels and chainwheels; added paragraphs 1.4 on Valve Construction and 1.5 on Description of Operation to Sec. 1, General; revised Table 1 in Sec. 4.3, Port diameter and minimum body shell thickness, to require that the wall thicknesses of ductile-iron construction be the same wall thicknesses as cast steel construction; added paragraph 4.3.9.4 on design methodology for the valve shafts; revised the metal-seat leakage requirements in Sec. 5.1.2.3; revised coating requirements in Sec. 4.4.3; added actuator pressure rating and actuator flow rating to nameplate requirements; and, added Appendix A on Installation, Operation, and Maintenance of Ball Valves.
This standard describes iron-body, resilient-seated gate valves with non-rising stems (NRS) and outside screw-and-yoke (OS&Y) rising stems, including tapping gate valves, for water supply service having a temperature range of 33º-125ºF (0.6º- 52ºC). These valves are intended for applications where fluid velocity does not exceed 16 ft/sec when the valve is in full open position. Major revisions made to the standard in this edition include the following: editorial changes to conform to current AWWA form and content; addition of reduced-thickness ductile-iron flanges; addition of stainless-steel alloys for use as a stem material; permitting the use of non-integral thrust collars for stems in NRS valves; addition of aluminum-bronze and silicon-bronze copper alloys; addition of 14-, 18-, and 36-in. valve sizes; addition of socket head and metric fasteners; requirement to use an anti-seize compound with stainless-steel bolts and nuts; and, removal of maximum phosphorus content.
This standard describes reduced-wall,
resilient-seated gate valves with non-rising stems (NRS) and outside screw-and-yoke (OS&Y) rising stems, including tapping gate valves, for water supply service having a temperature range of 33º to 125ºF (0.6º to 52ºC). These valves are intended for applications where fluid velocity does not exceed 16 ft/sec (4.9 m/sec) when the valve is in the fully open position. Major revisions made to the standard in this edition include the following: revised to cover 42-in. NPS and 48-in. NPS sizes; revised to include integral and non-integral thrust collar stem designs; revised to include reduced flange thickness for flanged-end valves; revised to include socket head and metric fasteners; added additional copper alloys to Table 5; and, revised to include the use of stainless-steel components (Sec. 4.2.3.5).
This standard establishes minimum requirements for
rubber-seated butterfly valves, 3 in. (75 mm) through 72 in. (1,800 mm) in diameter, with various body and end types, for fresh water having a pH range from 6-12 and a temperature range from 33º-125ºF (0.6º-52ºC). This standard covers rubber-seated butterfly valves suitable for a maximum steady-state fluid working pressure of 250 psig (1,723 kPa), a maximum steady-state differential pressure of 250 psi (1,723 kPa), and a maximum fully open fluid velocity of 16 ft/sec (4.9 m/sec) based on nominal valve size. The major revisions made to the standard in this edition include the following: permeation language was moved to the Foreword under Special Issues, Sec. II.C; and, new requirements were provided for mechanical-joint-end valves.
This standard describes
electric motor actuators for valves and slide gates in water, wastewater, and reclaimed water utility systems. Electric motor actuators are designed to produce a multi-turn rotary motion output to actuate a multi-turn valve or gate, or to actuate an external gear head for quarter-turn valves. Electric motor actuators not requiring external gear heads for quarter-turn valves are defined in Sec. 4.4.1.2. This is the first edition of this standard, and therefore, there are no revisions.
This standard describes only iron body, non-assisted,
swing-check valves, 2-in. through 24-in. (50-mm through 600-mm) NPS, with mechanical-joint or flanged ends that are installed in approximately level settings in water systems. The manufacturer should be consulted for special conditions. Check valve sizes described in this standard are 2-, 2 1/2-, 3-, 4-, 6-, 8-, 10-, 12-, 14-, 16-, 18-, 20-, and 24-in. (50-, 65-, 75-, 100-, 150-, 200-, 250-, 300-, 350-, 400-, 450-, 500-, and 600-mm) NPS. Sizes refer to the nominal diameter of the waterway through the inlet and outlet connections and the seat ring. Major revisions made to the standard in this edition include the following: the pressure ratings were revised in Sec. 1.1.4; standard end-to-end dimensions were moved from the appendix to the body of the standard in Sec. 4.4.2 and Table 2; new ductile-iron flange thicknesses were added to Sec. 4.4.7.1 and Table 3; and, a new appendix titled "Installation, Operation, and Maintenance of Swing- Check Valves for Waterworks Service" was added.
This standard describes 1/2 in. (13-mm) through 6 in. (150-mm)
air-release valves and 1/2 in. (13-mm) through 20-in. (500-mm) air/vacuum and combination air valves having gray cast-iron or ductile-iron bodies and covers. The valves are designed for use in water systems with maximum working pressures of 300 psig (2,070 kPa [gauge]) and water temperatures ranging from above freezing to a maximum of 125ºF (52ºC). Major changes made to the standard in this revision include the following: added requirements for throttling devices in Sec. 4.3.3; and, added requirements for slow-closing devices in Sec. 4.3.4.
This standard describes resilient-seated cast-iron
eccentric plug valves, 3 in. (75 mm) through 72 in. (1,800 mm) in diameter, with flanged, grooved, or mechanical-joint ends, for water, wastewater, and reclaimed water systems having a pH range from 6 to 12 and a temperature range from 33ºF to 125ºF (0.6ºC to 52ºC). The minimum design pressure shall be 175 psig (1,208 kPa) for 3 in. through 12 in. (75 mm through 300 mm) sizes and 150 psig (1,034 kPa) for 14 in. through 72 in. (350 mm through 1,800 mm) sizes. Major changes made to the standard in this revision include the following: expanded Scope and Purpose to include wastewater and reclaimed water service; added references to ANSI/AWWA Standards C541 and C542 for power actuator requirements; and, removed contractual language from the body of the standard.
This standard describes
hydraulic and
pneumatic cylinder and vane-type actuators for operation of valve and slide gates in utility systems. This is the first edition of this standard, and therefore, there are no revisions.
